750-1250KG Unbrake Axle with 5 Bolts Hub
Use: Trailer Parts
Parts: Trailer Axles
Port: Qingdao, China
Delivery Time: 35 days
Min. Order: 100 Piece/Pieces
Payment Type: D/P, D/A, T/T, MoneyGram, Paypal, etc.
Parameters:
| 5*4.5" 6*5.5" wheel bolts pattern | |||||
| NO. | Description | QTY | option 1 | option 2 | |
|---|---|---|---|---|---|
1 |
axle shaft |
1 |
45mm Rd / Sq solid |
50*5mm Rd / Sq tube |
|
2 |
Oil seal |
2 |
AC00900500 |
AT01700301 |
|
3 |
inner bearing |
2 |
LM67048/10 |
L44649/10 |
|
4 |
idler hub |
2 |
AT01700107 |
AT01700102 |
|
5 |
wheel bolt |
10.12 |
1/2F0UNF |
7/16H-20UNF |
|
6 |
outer bearing |
2 |
LM11949/10 |
L44649/10 |
|
7 |
flat washer |
2 |
AC00500402 |
AC00201001 |
|
8 |
castle nut |
2 |
AC00500403 |
AC00200701 |
|
9 |
split pin |
2 |
AC00500404 |
AC00200404 |
|
10 |
dust cap |
2 |
AC00500405 |
AC00300601 |
|
other PCD 5*4.25", 5*4.75", 6*150... are available too. |
|||||
